3U 3 Way Horizontally Rack Mounted Fan Tray

Part: D502010
Now Made In The UK by Power Distribution Specialist Integra PDU

  • Get Concentrated Airflow To Where You Need It At 90 Cubic Feet Per Minute Per Individual Fan
  • The 3U 19" Horizontally Rack Mounted Fan Unit Is Designed For Cooling Hot-Spots In A Server Rack
  • This Versatile Product Has Been Proven To Solve Cooling Issues In Many Settings, Not Just Within The Confines Of A 19 Inch Server Rack Or Data Cabinet
  • Low Noise Fan Option Available
  • Bespoke Units Available Subject to MoQ - Please Get In Touch

Please enter a valid email address

  • from £102.20
  • Incl. VAT: £122.64

0 reviews / Write a review

Takes 3U of rack space in your server cabinet

Dimensions are: 486mm (w) x 132mm (h) x 43mm (d)


Fan Specification

Standard

Model:

DP201A

Rated Voltage:

220-240 VAC 50/60 Hz

Operating Voltage Range:

185-245 VAC

Starting Voltage:

185 VAC (25 deg. C POWER ON/OFF)

Rated Speed:

2750/3050 RPM ± 10%

Air Delivery:

87/107 CFM

Static Pressure:

0.26/0.32 Inch-H²O

Rated Current:

0.125/0.11 AMP

Rated Power:

20/19 WATTS

Noise Level:

45/50 dB(A)

Direction of Rotation:

Counter-clockwise viewed from the front of fan blade

Operating Temperature:

-10 tp +70 deg. C

Storage Temperature:

-40 to +70 deg. C

Bearing System:

Precision ball bearing system

Weight:

550g

Safety:

TUV/UL/CUR/VDE/CE Approvals
Product Information
Fan Type Low Noise
Mount Format 3U 19 Inch
