TP Link TL-ER605 Omada Gigabit VPN Router

Part: H010700
  • Brand: TP-Link
  • Availability: In Stock

Secure & Reliable Gigabit VPN Router From TP-Link

  • Up To 3 WAN Ports For Various Internet Connections
  • Multi-WAN Load Balancing Function
  • Mobile 4G/3G Broadband Support Via USB Port
  • 5x Gigabit RJ45 Ports
  • High Security & VPN Features - Supports IPSec/PPTP/L2TP VPN over IPSec/SSL
  • Integrates With TP-Link Omada Solution For Centralised Management

Please enter a valid email address

  • from £43.53
  • Incl. VAT: £52.24

0 reviews / Write a review

  • Integrated into Omada SDN: Centralized Cloud Management and Intelligent Monitoring.
  • Centralized Management: The router can be managed through the Omada cloud or the Omada app, making it easy to monitor, configure and manage from anywhere.
  • Five Gigabit Ports: These ports provide high speed wired connectivity for your computers, printers and other devices.
  • Up to 3 WAN Ethernet Ports: 1 gigabit WAN port and 2 gigabit WAN/LAN ports with load balance to connect to multiple broadband providers.
  • One USB WAN Port for Mobile Broadband: This USB port allows connection to mobile broadband via 4G/3G modem for WAN backup.
  • Highly Secure VPN: Supports up to 20× LAN-to-LAN IPsec, 16× OpenVPN*, 16× L2TP, and 16× PPTP VPN connections.
  • Abundant Security Features: Advanced firewall policies, DoS defense, IP/MAC/URL filtering, and more security functions protect your network and data against threats.
HARDWARE FEATURES
Standards and Protocols• IEEE 802.3, 802.3u, 802.3ab, IEEE 802.3x, IEEE 802.1q
• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP
Interface• 1 Fixed Gigabit WAN Port
• 2 Fixed Gigabit LAN Ports
• 2 Changeable Gigabit WAN/LAN Ports
• 1 USB 2.0 Port (Connecting 4G/3G Modem as WAN Backup‡)
Network Media• 10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
• 100BASE-TX: UTP category 5, 5e cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
• 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)
Fan QuantityFanless
ButtonReset Button
Power SupplyExternal 12V/1A DC Adapter
PoE Budget-
Flash128 MB NAND
DRAM256 MB DDR
LEDPWR, SYS, WAN (Link/Act), LAN (Link/Act), USB
Dimensions ( W x D x H )6.2 × 4.0 × 1.0 in (158 × 101 × 25mm)
Protection4 kV surge protection
EnclosureSteel
MountingDesktop/Wall-mount
Max Power Consumption7.94 W
PERFORMANCE
Concurrent Session150,000
New Sessions /Second2,600
NAT (Static IP)• Upload: 945.77 Mbps
• Download: 945.56 Mbps
• Bi-Directional: 1808.29 Mbps
NAT(DHCP)• Upload: 945.93 Mbps
• Download: 945.43 Mbps
• Bi-Directional: 1808.11 Mbps
NAT(PPPoE)• Upload: 940.44Mbps
• Download: 940.52 Mbps
• Bi-Directional: 1804.27 Mbps
NAT (L2TP)• Upload: 845.64 Mbps
• Download: 802.65 Mbps
• Bi-Directional: 931.96 Mbps
NAT (PPTP)• Upload: 771.66 Mbps
• Download: 874.81 Mbps
• Bi-Directional: 999.54 Mbps
64 Byte Packet Forwarding Rate• Upload/Download: 1,402,238 pps
• Bi-Directional: 1,681,548 pps
IPsec VPN Throughput• ESP-MD5-AES256: 171.26 Mbps
• ESP-SHA1-AES256: 224.86 Mbps
• ESP-SHA2-AES256: 248.04 Mbps
OpenVPN• 21.70 Mbps
L2TP VPN Throughput• Unencrypted: 864.65 Mbps
• Encrypted: 47.11 Mbps
PPTP VPN Throughput• Unencrypted: 703.20 Mbps
• Encrypted: 76.65 Mbps
SSL VPN Throughput-
66 Byte Packet forwarding rate• Upload/Download: 954.50 Mbps
• Bi-Directional: 1130.00 Mbps
1,518 Byte Packet forwarding rate• Upload/Download: 997.50 Mbps
• Bi-Directional: 1965.00 Mbps
BASIC FUNCTIONS
WAN Connection Type• Static/Dynamic IP
• PPPoE
• PPTP
• L2TP
• Mobile Broadband: 4G/3G modem for backup via USB port‡
MAC CloneModify WAN/LAN MAC Address†
DHCP• DHCP Server/Client
• DHCP Address Reservation
• Multi-net DHCP*
• Multi-IP Interfaces*
IPv6StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough
VLAN802.1Q VLAN
IPTVIGMP v2/v3 Proxy, Custom Mode, Bridge Mode
ADVANCED FUNCTIONS
ACLIP/Port/Protocol/Domain Name Filtering
Advanced Routing• Static Routing
• Policy Routing
Bandwidth ControlIP-based Bandwidth Control
Load Balance• Intelligent Load Balance
• Application Optimized Routing
• Link Backup (Timing§, Failover)
• Online Detection
NAT• One-to-One NAT§
• Multi-Net NAT
• Virtual Server
• Port Triggering§
• NAT-DMZ
• FTP/H.323/SIP/IPSec/PPTP ALG, UPnP
Security• SPI Firewall
• VPN Passthrough
• FTP/H.323/PPTP/SIP/IPsec ALG
• DoS Defence, Ping of Death
• Local Management
Session LimitIP-based Session Limit
VPN
IPsec VPN• 20 IPsec VPN Tunnels
• LAN-to-LAN, Client-to-LAN
• Main, Aggressive Negotiation Mode
• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
• IKEv1/v2
• MD5, SHA1 Authentication Algorithm
• NAT Traversal (NAT-T)
• Dead Peer Detection (DPD)
• Perfect Forward Secrecy (PFS)

PPTP VPN• PPTP VPN Server
• 10 PPTP VPN Clients**
• 16 Tunnels
• PPTP with MPPE Encryption
L2TP VPN• L2TP VPN Server
• 10 L2TP VPN Clients**
• 16 Tunnels
• L2TP over IPSec
OpenVPN• OpenVPN Server*
• 10 OpenVPN Clients*△
• 16 OpenVPN Tunnels*
SECURITY
Filtering• WEB Group Filtering§
• URL Filtering
• Web Security§
ARP Inspection• Sending GARP Packets§
• ARP Scanning§
• IP-MAC Binding§
Attack Defense• TCP/UDP/ICMP Flood Defense
• Block TCP Scan (Stealth FIN/Xmas/Null)
• Block Ping from WAN
Access ControlSource/Destination IP Based Access Control
AUTHENTICATION
Web Authentication• No Authentication
• Simple Password*
• Hotspot（Local User / Voucher* / SMS* / Radius*）
• External Radius Sever
• External Portal Sever*
• Facebook*
MANAGEMENT
Omada AppYes
Centralized Management• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
• Omada Cloud-Based Controller
Cloud AccessYes (Through OC300, OC200, Omada Software Controller, or Omada Cloud-Based Controller)
ServiceDynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)
Maintenance• Web Management Interface
• Remote Management
• Export & Import Configuration
• SNMP v1/v2c/v3
• Diagnostics (Ping & Traceroute)§
• NTP Synchronize§
• Syslog Support
Zero-Touch ProvisioningYes. Requiring the use of Omada Cloud-Based Controller.
Management Features• Automatic Device Discovery
• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule
• Captive Portal Configuration
OTHERS
CertificationCE, FCC, RoHS
Package Contents• Gigabti VPN Router ER605
• Power Adapter
• RJ45 Ethernet Cable
• Quick Installation Guide
System RequirementsMicrosoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
Environment• Operating Temperature: 0–40 ℃ (32–104 ℉);
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
